- Twin ferrule design.
- Materials in Stainless Steel SS316L, SS317L, Super Duplex, Carbon steel, Hastelloy, Monel. Other material available upon request
- Available in both inches and metric sizes in various end connections
- Low torque assembly
- Positive leak free sealing after continuous assembly and re-assembly
- Good vibration resistance
- Excellent Leak-Free Sealing System in high thermal stresses and high impulse.
|
|
 |
| |
| Download PDF catalogue | Back to top |
|
| |
| |
- 37° Flare Sealing .
- Materials available in Stainless Steel SS316L, Brass, Carbon steel
- According to SAE J514 & ISO 8434-2
- Available in both inches and metric sizes in various end connections
- Used mainly in hydraulic systems
- Exceptional performance under extreme vibration and thermal shocks
|
|
 |
| |
| Download PDF catalogue | Back to top |
|
| |
| |
- According to DIN2353 & ISO8434-1
- Materials available in Stainless Steel SS316L, Brass, Carbon steel
- Available in metric sizes only from 6mm to 42mm
- Commonly used in hydraulic systems.
- Flareless Bite Type Cutting Ring design
- Cutting ring designed with optimised double biting point for better sealing
|
|
 |
| |
| Back to top |
|
| |
| |
- According to JIS B2351
- Materials available in Stainless Steel SS316L, Carbon Steel, Brass
- Used mainly on pipes where welding or flaring is not recommended
- Positive sealing after repeated dis-assemble and re-assembly
- Flareless Bite Type Single Cutting Ring Design
|
|
 |
| |
| Back to top |
|
| |
| |
- NPT(ASME B1.20.1), ISO/BSP, and Unified threads
- Materials available in Stainless steel SS316L, Brass, Carbon steel
- Available in 1/8" to 2" threaded connection
- Instrumentation grade pipe fittings
- Standard packaging include plastic caps on the Male threads to prevent damage during shipping
|
|
 |
| |
| Download PDF catalogue | Back to top |
|
| |
| |
- Cone and thread design connections available in MP, HP and type M
- Working pressure of up to 60,000 PSIG
- Fittings can be made disassembled and reassembled easily to provide a reliable leak tight
- Weep holes for instant leak detection and safety
- Fittings are machined from 316 stainless steel
|
|
 |
| |
| Back to top |
|
| |
| |
- According to ASME B16.11, MSS SP-79, MSS SP-83
- Materials available in Stainless steel and Carbon steel
- Available in #3000 LB and #6000 LB
- Forged fittings in threaded ends and socket weld fitting
|
|
 |
| |
